| CAR BRAND | MODAL | YEAR |
| CHRYSLER | TOWN & COUNTRY 3.6L V6 | 2012-2016 |
| DODGE | GRAND CARAVAN 3.6L V6 | 2012-2020 |
| DODGE | RAM C/V 3.6L V6 | 2012-2016 |
| VOLKSWAGEN | ROUTAN 3.6L V6 | 2012-2014 |
| Important properties |
|
|
| OE NO: 512493 |
|
New and old: New |
| ORIGION: ZheJiang China |
|
PURPOSE: Original replacement |
| GUARANTEE: 12 months or 50000 kms |
|
BRAND: XATM |
| SIZE: Standard size |
|
APPLICATION: AUTO PARTS |
| USAGE: Aftermarket |
|
PAYMENT: TT |
| DELIVERY TIME: 15-45 Days |
|
|
| PACKAGE: Natural box/XATM color box/Customized box |
|
|
| Bearing materials | GCr15=SAE52100 |
| Flange materials | 55# steel |
| Ball/roller materials | GCr15=SAE52100 |
| Cage materials | Top grade PA66+GF25 |
| Seal materials | Stainless steel+ NBR |
| Wheel stud grade | 10.9 |
| Bearing rings hardness control | 60-65 HRC |
| Ball/roller hardness control | 61-66 HRC |
|
Inner and outer ring race max roughness control |
≤0.1μm |
|
Inner and outer ring race max roundness control |
≤3 μm |
| Production inspection | 100% |
VICKERS HARDNESS TESTER
METALLURGICAL MICROSCOPE
ROUNDNESS MEASURING INSTRUMENT
COORDINATE MEASURING MACHINE
SURFACE PROFILOMETER
SPECTROMETER
SURFACE PROFILOMETER
UNIVERSAL LENGTH GAUGE
